介電強度 ( Dielectric Strength )

600VAC/1S

絕緣電阻( Insulation Resistance )

100MΩ, 500VDC

環境溫度 ( Ambient Temperature )

-20°C   ~   +50°C

絕緣等級 (Insulation Class)

Class B

徑向間隙 ( Radial Play )

0.025mm@4N

軸向間隙 ( Axial Play )

0.3mm@4N

最大徑向負載 ( Max radial force )

15N距法蘭10mm

( 10mm From the flange)

最大軸向負載 ( Max axial force)

5N

極數  ( Number of poles )

2

相數  ( Number of phases )

3

額定電壓 ( Rated  voltage )

VDC

6

空載轉速 (No load speed)

RPM

11000

空載電流 (No load current)

A

0.1

額定轉矩 ( Rated torque)

mN.m

3.6

額定電流 (Rated current)

A

0.8

額定速度 ( Rated speed )

RPM

                 10000

額定功率 ( Rated power )

W

3.8

額定效率 (Rated efficiency)

%

70%

峰值轉矩 ( Peak torque )

mN.m

10.8

峰值電流 ( Peak current )

A

2.4

線電阻 ( Line to line resistance )

ohms@20℃

1.3

線電感 ( Line to line inductance )

mH

0.06

轉矩常數 ( Torque constant )

mNm/A

5.27

反電勢 ( Back EMF )

Vrms/Krpm

0.39

外殼-環境熱阻( Housing - Ambient thermal resistance)

K/W

7.32

電機熱時間常數(Motor thermal time constant)

S

869

繞組最高允許溫度(Max temperature of winding)

℃

155

電氣時間常數(Electrical time constant)

ms

0.046

黃色(Yellow)

UL1332 AWG20

U相 ( Phase U )

紅色( Red)

V相 ( Phase V )

黑色(Black)

W相 ( Phase W )
